1. The stripping and tapping terminal machine adopts frequency conversion technology to precisely control the variable speed motor, and is equipped with a high-precision control module and transmission mechanism. It has the characteristics of low noise, low power consumption and high speed, and has a significant effect on multi-core power cables.
2. The stripping action is driven by the cylinder, the action speed is fast, and the positioning is accurate; The waste material after stripping adopts vacuum suction method, which is clean, convenient and simple. The pressure is driven by a turbine deceleration, and the pressure is highly precise.
3. The machine can change the overall speed through the operation panel, so as to adapt to the operator's proficiency.
4. The pneumatic part is all made of brand components, which is durable and accurate, and is suitable for all kinds of horizontal strip open terminals, and the terminal and the stripping position are crimped to achieve unity.

Key words:

Model:	ZJ-20S
Function:	Stripping, Crimping.
Dimension:	400530830mm
Weight:	70Kg
Stroke:	30mm
Work Voltage:	220V/50Hz/60Hz(Optional110V)
Compressed-Air Required:	0.6-0.8Mpa，Dry，Clean。
Stripping Length:	1-10mm
Stripping Accuracy:	0.05-0.1mm
Productivity:	1.2s/Stroke
Maximum Crimping Force:	2.0T(Otptional:3.0T)
Range of Processed Wire:	0.1-2.5mm²
Warranty:	1 Year(Consumables and human causes excluded)

*Some products may can not be processed, even if the parameters are included. We are happy to process your samples.
